Schneider Electric LC1D115P7 TeSys D 3-Pole Contactor, 115A AC-3, 230V AC Coil

Series#: Contactor -> Schneider -> TeSys D
- Schneider Electric LC1D115P7 TeSys D 3-Pole Contactor, 115A AC-3, 230V AC Coil
- We have large inventory for Schneider TeSys D contactors and motor control solutions.
- 100% Original and new, In stock by Eaton Company.
- Delivery time: Ready in stock and 1 days for ship out
- MOQ: 1pcs

Availability:



Inquire

Model:
LC1D115P7
Brand:
Schneider Electric

Product Description

The LC1D115P7 is a high-current 3-pole contactor rated 115A AC-3 (55kW @ 400V) with a 230V AC coil. It features screw clamp power terminals and 2NO+2NC auxiliary contacts. Suitable for direct-on-line motor starting, power distribution switching, and heavy industrial load control in manufacturing plants, HVAC systems, and pumping stations.

**Q: What is the difference between AC-3 and AC-1 ratings?**
A: AC-3 rating applies to motor starting/stopping (making 6×In, breaking 1×In). AC-1 rating (~200A for LC1D115) applies to resistive/non-inductive loads like heating.

Technical Specifications

Schneider Electric LC1D115P7
Contactor -> Schneider -> TeSys D \| Schneider Electric LC1D115P7 TeSys D 3-Pole Contactor, 115A AC-3, 230V AC Coil
Feature	Specification
Feature	Specification
Rated Operational Current (AC-3)	115 A
Rated Power (400V AC-3)	55 kW
Number of Poles	3 NO
Coil Voltage	230V AC (50/60 Hz)
Built-in Auxiliary Contacts	2 NO + 2 NC
Terminal Type	Screw clamp
Mechanical Life	> 10 million ops
Mounting	Panel / DIN rail adapter
Standards	IEC 60947-4-1
AC-1 Rating (resistive)	200 A at <=440V AC
AC-3 Rating (motor)	115 A at <=440V AC
Motor Power AC-3 400V	55 kW
Coil Voltage	230V AC 50/60 Hz
Coil Inrush Power	~500 VA
Coil Holding Power	~22 VA
Rated Insulation Voltage	1000 V (IEC)
Rated Impulse Voltage	8 kV
Auxiliary Contacts	2 NO + 2 NC
Mechanical Durability	10 million cycles
Electrical Durability AC-3	1.2 million cycles
Short-Time Withstand Current	1100 A for 1s
Associated Fuse Rating	160 A gG
Dimensions (HxWxD)	158 x 120 x 136 mm
Weight	~2.4 kg
