Schneider Electric LC1D18BD TeSys D 3-Pole Contactor, 18A AC-3, 24V DC Coil

Series#: Contactor -> Schneider -> TeSys D
- Schneider Electric LC1D18BD TeSys D 3-Pole Contactor, 18A AC-3, 24V DC Coil
- We have large inventory for Schneider TeSys D contactors and motor control accessories.
- 100% Original and new, In stock by Eaton Company.
- Delivery time: Ready in stock and 1 days for ship out
- MOQ: 1pcs

Availability:



Inquire

Model:
LC1D18BD
Brand:
Schneider Electric

Product Description

The LC1D18BD is an 18A 3-pole contactor with 24V DC coil from the TeSys D series. Rated 7.5kW at 400V AC-3, it is ideal for PLC-controlled motor starting applications where direct DC coil drive is preferred. With built-in auxiliary contacts and 45mm DIN rail mounting, it suits compact control panel designs for conveyors, pumps, fans, and general automation.

**Q: Can the LC1D18BD directly interface with a PLC output?**
A: Yes, the 24V DC coil can be driven directly by PLC transistor outputs (within the coil power rating), eliminating the need for interposing relays.

Technical Specifications

Schneider Electric LC1D18BD
Contactor -> Schneider -> TeSys D \| Schneider Electric LC1D18BD TeSys D 3-Pole Contactor, 18A AC-3, 24V DC Coil
Feature	Specification
Feature	Specification
Rated Operational Current (AC-3)	18 A
Rated Power (400V AC-3)	7.5 kW
Number of Poles	3 NO
Coil Voltage	24V DC
Built-in Auxiliary Contacts	1 NO + 1 NC
Mounting	DIN rail / panel
Width	45 mm
Standards	IEC 60947-4-1
AC-1 Rating (resistive)	32 A at <=440V AC
AC-3 Rating (motor)	18 A at <=440V AC
Motor Power AC-3 400V	7.5 kW
Rated Insulation Voltage (Ui)	690 V (IEC)
Rated Impulse Voltage (Uimp)	6 kV
Thermal Current (Ith)	32 A at <=60 C
Mechanical Durability	15 million cycles
Electrical Durability AC-3	2 million cycles
Max Operating Rate	3600 cycles/h
Short-Time Withstand Current	336 A for 1s
Associated Fuse Rating	32 A gG (Type 2)
Dimensions (HxWxD)	77 x 45 x 86 mm
Weight	~0.32 kg
Certifications	CE, UL, CSA, CCC, Marine
