The Siemens SIMATIC ET 200SP HA AQ 8xI HART HA (6DL1133-6EW00-0PH1) is an 8-channel analog output module for the ET 200SP High Availability distributed I/O system. It provides configurable voltage and current outputs per channel with integrated HART communication and 16-bit resolution. The module features extensive diagnostics including wire break, short circuit, and supply voltage monitoring, and complies with NAMUR NE 43 standards. Output behavior on communication loss is configurable to either hold the last value or switch to a predefined substitute value. Designed for redundant H-System configurations with S7-410 controllers, it is ideal for controlling actuators, control valves, and positioners in oil & gas, chemical, and power generation process plants.
Q: What output types are supported?
A: Both voltage and current outputs are supported, configurable per channel.
Q: Is HART communication available on all channels?
A: Yes, integrated HART communication is available on all 8 channels.
Q: What happens if communication with the PLC is lost?
A: Output behavior is configurable - either hold the last value or switch to a substitute value.
Q: Is this module NAMUR compliant?
A: Yes, it complies with NAMUR NE 43 standards for analog output signals.
Q: Can this module be used in safety applications?
A: Yes, the module is designed for safety-rated systems when properly configured
FAQ
.
