The Siemens SIMATIC ET 200SP HA DI 16xNAMUR HA (6DL1134-6AF00-0PH1) is a 16-channel digital input module for the ET 200SP High Availability distributed I/O system, specifically designed for safety-related applications. It accepts NAMUR proximity sensor signals and standard 24V DC inputs, with parameterizable input delay from 0.1 ms to 20 ms. Comprehensive diagnostics include wire break and short circuit to L+ detection per channel. Select channels support fast counting functions, making it versatile for both standard monitoring and pulse counting applications. Commonly used for valve position feedback and safety interlock monitoring in emergency shutdown systems, fire & gas systems, and burner management applications in oil & gas, chemical, and power generation industries.
Q: What sensor types are compatible?
A: NAMUR sensors (intrinsic safety) and 24V DC digital inputs, depending on configuration and Base Unit.
Q: Is this module suitable for safety applications?
A: Yes, it is specifically designed for use in safety-related applications such as valve position feedback.
Q: Can this module perform counting functions?
A: Yes, fast counting and counter functions are available on select channels.
Q: What is the input delay range?
A: The input delay is parameterizable from 0.1 ms to 20 ms.
Q: What diagnostics are available?
A: Wire break detection and short circuit to L+ detection are available per channel
