| Model | SH-302*1 | SH-303A | SH-305 | SH-308 | SH-110 | SH-114 | SH-614A |
| Type | Standard Shielded Cylindrical | Standard Shielded Threaded | Standard Shielded Thin |
|
|
|
|
| Shape | ø2.8×12 Cylindrical | ø3.8×18 Cylindrical | ø5.4×18 Cylindrical | ø8×18 Cylindrical | M10×18 Threaded | M14×18 Threaded | 14×30×4.8 Thin |
| Detectable object | Ferrous metal (see Characteristics for nonferrous metals) |
|
|
|
|
|
|
| Standard target (iron, t=1 mm <font color=”#0099ff”>0.04″</font>) | 5 x 5 mm 0.20″*2 | 10 x 10 mm 0.39″ x 0.39″*2 | 15 x 15 mm 0.59″ x 0.59″*2 |
|
|
|
|
| Stable detecting range | 0 to 0.6 mm 0.02″ | 0 to 0.8 mm 0.03″ | 0 to 1 mm 0.04″ | 0 to 2 mm 0.08″ | 0 to 5 mm 0.20″ |
|
|
| Maximum detecting distance | 1.6 mm 0.06″ | 2 mm 0.08″ | 3 mm 0.12″ | 5 mm 0.20″ | 10 mm 0.39″ |
|
|
| Repeatability | 0.001 mm 0.00004″*2 | 0.002 mm 0.00008″*2 |
|
|
|
|
|
| Hysteresis | 0.03 mm 0.001″*2 | 0.05 mm 0.002″*2 | 0.01 mm 0.0004″*2 | 0.015 mm 0.0006″*2 |
|
|
|
| Temperature characteristics | 0.3%/°C*2 | 0.08%/°C*2 | 0.04%/°C*2 |
|
|
|
|
| Enclosure rating | IP67 |
|
|
|
|
|
|
| Ambient temperature | -10 to +60 °C 14 to 140 °F (No freezing) |
|
|
|
|
|
|
| Relative humidity | 35 to 85 % RH (No condensation) |
|
|
|
|
|
|
| Vibration resistance | 10 to 55 Hz, Double amplitude 1.5 mm 0.06″, 2 hours in each of the X, Y, and Z directions |
|
|
|
|
|
|
| Weight | Approx. 30 g | Approx. 35 g | Approx. 45 g | Approx. 55 g | Approx. 63 g | Approx. 60 g |
|
