Omron PLC CJ-series CJ2M Pulsus I/O Moduli CJ2M-MD211 CJ2M-MD212

Series#: Omron PLC

Omron PLC CJ-series CJ2M Pulsus I/O Modules CJ2M-MD211 CJ2M-MD212
Omron PLC Controller Module CJ2M-series
Partes automationes Omron supplere possumus, ut Omron PLC, Omron Servo Motor, Omron HMI, Omron VFD et Omron Nullam et Omron Sensor et effect.
C% originale et novum, In Stock ab Omron Automation
Delivery time: Ready in stock and 1 days for ship out
MOQ: 1pcs

Availability:



inquire

Specification

Series#: Omron PLC

Omron PLC CJ-series CJ2M Pulsus I/O Modules CJ2M-MD211 CJ2M-MD212
Omron PLC Controller Module CJ2M-series
Partes automationes Omron supplere possumus, ut Omron PLC, Omron Servo Motor, Omron HMI, Omron VFD et Omron Nullam et Omron Sensor et effect.
In Coberry possumus te praebere cum notam Factory novam opertam ab Originali Warra
Emptio Used Partes offerre compendia magna super novam
Emptio refurbished offerre potest per novam compendia magna

Download Munual

Exemplar Pulsus I / O Modules

CJ2M-MD211 (Sinking-type) CJ2M-MD212 (Sourcing-type)

Interface

40-pin MIL iungo

Pulsus Inputs

Adhiberi possunt pro normalibus inputibus, interrumpere inputationibus, responsionibus inputibus velox, vel initibus contra celeritatem initibus. (munus cuiuslibet initus eligendus est in PLC Setup).

Input modum: Line-coegi initus vel 24-VDC initus (electus a wiring)

Normalis Inputs

20 max. (X per Pulsus I/O OMNIBUS)

Input constantes: Pone in PLC Setup (0, 0.5, 1, 2, 4, 8, 16, vel 32 ms). Default: 8 ms

Interpellare Inputs et Velox-responsio Inputs

8 max. (4 per Pulsus I/O OMNIBUS)

Input signum minimum DE latitudinis leguminis: 30 ms

Summus celeritatem Inputs

4 max. (II per Pulsus I/O OMNIBUS)

Modus initus: differentialis-phase (´4) pulsus, pulsus + directio, sursum/down pulsus vel pulsus incrementum Maximum responsionis frequentiae: 50 kHz pro incrementis differentialibus vel 100 kHz pro una periodo computationis: modus linearis vel modus circularis (anulus)

Numerare valorem: 32 bits

Counter reset: Phase Z

Pulsus outputs

Poni possunt pro normalibus outputs, pulsus outputs, vel PWM outputs. Munus cuiusque output eligendus est in PLC Setup.

Modus output: Submersio vel transistor outputs transmigrans (Modo determinatur per Pulsus I/O exemplar exemplar.)

Normalis Outputs

12 max. (6 per Pulsus I/O OMNIBUS)

Pulsus outputs

4 max. (2 per Pulsus I/O OMNIBUS)

Modus output: CW/CCW seu legumen + directio (Modo determinatur I/O wiring et instructiones in programmate scalae adhibitae).

Frequentiam output: I pps ad C kpps (per incrementa I pps)

Output Modus: Modus continuus (pro velocitate control) vel modus independens (pro positio potestate) Output pulsus: Coordinatae relativae: 0000 0000 ad 7FFF FFFF hex (0 ad 2,147,483,647 pulsus) Coordinatae absolutae: 8000 0000 ad 7FFF FFFF hex (-2,147,/483,648,647), Acceleratio linearum orceleratio. S-curva

Origin quaerere munus: Subnixus

PWM Outputs

4 max. (II per Pulsus I/O OMNIBUS)

Frequentia output: 0.1 ad 6,553.5 Hz (in incrementis 0.1-Hz) vel 1 ad 32,800 Hz (in incrementis 1-Hz) Officii ratio: 0.0% ad 100.0% (in 0.1% incrementis)
