Article number | 6ES7417-5HT06-0AB0 |
Article number | CPU417-5H PN/DP, 32MB F. S7-400H/F/FH |
General information |
|
Product type designation | CPU 417-5H PN/DP |
HW functional status | 1 |
Firmware version | V6.0 |
Product function |
|
● Isochronous mode | No |
Engineering with |
|
● Programming package | As of STEP 7 V5.5 SP2 with HF1 |
CiR – Configuration in RUN |
|
CiR synchronization time, basic load | 60 ms |
CiR synchronization time, time per I/O byte | 0 µs |
Supply voltage |
|
Rated value (DC) |
|
● 24 V DC | No; Power supply via system power supply |
Input current |
|
from backplane bus 5 V DC, typ. | 1.6 A |
from backplane bus 5 V DC, max. | 1.9 A |
from backplane bus 24 V DC, max. | 150 mA; 150 mA per DP interface |
from interface 5 V DC, max. | 90 mA; At each DP interface |
Power loss |
|
Power loss, typ. | 7.5 W |
Memory |
|
Type of memory | other |
Work memory |
|
● integrated | 32 Mbyte |
● integrated (for program) | 16 Mbyte |
● integrated (for data) | 16 Mbyte |
● expandable | No |
Load memory |
|
● expandable FEPROM | Yes; with Memory Card (FLASH) |
● expandable FEPROM, max. | 64 Mbyte |
● integrated RAM, max. | 1 Mbyte |
● expandable RAM | Yes |
● expandable RAM, max. | 64 Mbyte |
Backup |
|
● present | Yes |
● with battery | Yes; all data |
● without battery | No |
Battery |
|
Backup battery |
|
● Backup current, typ. | 180 µA; Valid up to 40°C |
● Backup current, max. | 1 000 µA |
● Backup time, max. | Dealt with in the module data manual with the secondary conditions and the factors of influence |
● Feeding of external backup voltage to CPU | 5 V DC to 15 V DC |
CPU processing times |
|
for bit operations, typ. | 7.5 ns |
for word operations, typ. | 7.5 ns |
for fixed point arithmetic, typ. | 7.5 ns |
for floating point arithmetic, typ. | 15 ns |
