| Yaskawa Sigma-7 SERVOPACKs SGD7W- |
1R6A |
2R8A |
5R5A |
7R6A |
| Maximum Applicable Motor Capacity [kW] |
0.2 |
0.4 |
0.75 |
1.0 |
| Continua Output Current [Arms] |
1.6 |
2.8 |
5.5 |
7.6 |
| Instantaneae Maximum Output Current [Arms] |
5.9 |
9.3 |
16.9 |
17.0 |
| Main Cir- cuit Power Supple |
270 VDC ad 324 VDC, -15% ad +10% |
| Praecipua Cir- cuit Input Current [Arms]* |
3.0 |
5.8 |
9.7 |
14 |
| Imperium Power Supple |
270 VDC ad 324 VDC, -15% ad +10% |
| Potestas Supple [kVA]* |
1.2 |
2 |
3.2 |
4.6 |
| Main Circuit Power Loss [W] |
23 |
40 |
76 |
92 |
| Control Circuit Power Loss [W] |
24 |
24 |
24 |
24 |
| Total Power Loss [W] |
47 |
64 |
100 |
116 |
| Item |
Specification |
| Imperium Methodo |
IGBT-substructio PWM potestate, sine fluctus vena coegi |
| Feedback Cum Rotary Servo Motor |
Vide encoder: XX frena vel XXIV bits (incremental encoder / absolute encoder) XXII bits (absolutum encoder) |
|
Cum Linearibus Servo Motor |
• Encoder linearis absolutus (Sensus solutionis ab absoluta encoder lineari dependet.) • Encoder linearis incrementalis (Sensus solutionis dependet ab incrementali encoder seu Serial Converter Unit). |
| Tempestas mentis Environ-
Aeris in circuitu Temperature |
-5°C ad 55°C. Consuetudo potest esse inter 55°C et 60°C. Refer ad sectionem sequentem ad specificationes perscrutandi.
Determinatio Specificationum (pagina 230) |
| Repono Tempera- turae |
-20°C ad 85°C |
| Aeris in circuitu Umor |
Relativum humiditatis 95% max. (Nihil frigore et condensatione) |
| Repono Umor |
Relativum humiditatis 95% max. (Nihil frigore et condensatione) |
| Vibratio Resistentia |
4.9 m/s2 |
| Repugnantia inpulsa |
19.6 m/s2 |
| Gradus Praesidium |
IP20 |
| Pollutio Degree |
2 • Oportet vapores corrosiuos aut flammabiles non esse.
• Aquam, oleum, vel chemicals non esse debet. • Nec pulvis, salia, nec pulvis ferreus. |
|
altitudo |
1,000 m vel minus. Cum contentione usus potest inter 1,000 m et 2,000 m. Refer ad sectionem sequentem ad specificationes perscrutandi.
Determinatio Specificationum (pagina 230) |
|
alii |
Non utere SERVOPACK in sequentibus locis: Locations electricitatis statice soni obnoxii, validi campi electromagnetici/magnetici vel radioactivity |
| Lorem signa |
UL 61800-5-1, CSA C22.2 No.274, EN50178, EN 61800-5-1, EN 55011 coetus I classis A, EN 61000-6-2, EN 61000-6-4, EN 61800-3 |
| Adscendens |
Basi conscendit vel eculeo conscendit |
| Celeritas Imperium dolor |
1:5000 (In Aureus aestimatus, finis inferioris celeritatis imperium range necesse est Servo Motore prohibere non est). |
|
Mobilitate coefficiens Fluctuatio* |
±0.01% celeritatis aestimatae max. (Ad onus fluctuatio 0% ad C%) |
|
0% de celeritate max rated. (Pro voltage fluctuatio ± X%) |
|
± 0,1% de celeritatis aestimatae max. (pro temperatus fluctuatio 25°C± 25°C) |
| Torque Control Pre- cision (Repeatability) |
±1% |
| Mollis Satus Tempus Profecti |
0 s ad 10 s (seorsim poni potest pro acceleratione et retardatione). |
